V15 1001
| Year of manufacture | 1959 |
| Manufacturer | Lokomotivbau "Karl-Marx" Babelsberg |
| Manufacturing number | 253 002 |
| Wheel arrangement | B |
| Genus | V15 |
| Type | |
| Owner | Dresden Traffic Museum (VMD) |
| Museum's vehicle since | 1994 |
| Accessibility | not always |
FORMERLY A PICTURE WAS PLACED HERE WHICH IS NO LONGER AVAILABLE DUE TO NEW LEGAL ISSUES CONCERNING HUMAN RIGHTS.
Technical Data
| Length over buffers | (mm) | 6 940 |
| Complete wheelbase | (mm) | 3 425 |
| Diameter of driving wheel | (mm) | 850 |
| Height over rail | (mm) | 3 425 |
| Operating weight (including all supplies) | (t) | 20 |
| Maximum speed | (km/h) | 30 |
| Power | (horse powers) | 150 |
| Brake type | K-GP m.Z. (Knorr) | |
| Axle load | (t) | 10 |
| Maximum tractive effort on starting | (Mp) | 6,6 |
| Engine type | 6 KVD 18 SRW | |
| Type of drive | Diesel hydraulic; W-K-K | |
| Track gauge | (mm) | 1 435 |
FORMERLY A PICTURE WAS PLACED HERE WHICH IS NO LONGER AVAILABLE DUE TO NEW LEGAL ISSUES CONCERNING HUMAN RIGHTS.
