| Length over buffers |
(mm) |
14 800 |
| Complete wheelbase |
(mm) |
11 700 |
| Diameter of driving wheel |
(mm) |
1 650 |
| Diameter of running wheel (front) |
(mm) |
1 000 |
| Diameter of running wheel (back) |
(mm) |
1 000 |
| Height over rail |
(mm) |
4 260 |
| Empty weight (engine + tender) |
(t) |
83,2 |
| Operating weight (including all supplies) |
(t) |
106 |
| Number of heating pipes |
|
134 |
| Condensating surface |
(m²) |
138,24 |
| Grill surface |
(m²) |
2,44 |
| Feeding device |
Injector (l/min) |
|
| |
Piston feed pump (l/min) |
|
| Maximum speed |
(km/h) |
100 |
| Power |
(horse powers) |
950 |
| Brake type |
|
|
| Axle load |
(t) |
|
| Maximum tractive effort on starting |
(Mp) |
32,6 |
| Boiler pressure |
(kp/cm²) |
12 |
| Diameter high pressure cylinder |
(mm) |
560 |
| Piston stroke |
(mm) |
630 |
| Coal reservoir |
(t) |
4,5 |
| Water reservoir |
(m³) |
12 |
| Track gauge |
(mm) |
1 435 |
